AUC- STE 326 Trinocular Stereozoom Microscope Zoom Range: 7×-45× Stand illumination options (Education / Laboratory Grade)

Trinocular Stereozoom with Pillar Stand No illumination

£550.00

AUC- STE 326 Trinocular Stereozoom Microscope Zoom Range: 7×-45× Stand illumination options (Education / Laboratory Grade)

£550.00

Trinocular Stereozoom Microscope

Zoom Range: 7×-45×

Stand illumination options

(Education / Laboratory Grade)

Microscope Options

AUC-STE-326T1 - Trinocular Stereozoom, with Pillar Stand, No illumination

AUC-STE-326T2 - Trinocular Sterozoom with Focus Stand with LED incident & Transmitted Light

Supplied with:

0.5x C Mount Adapter
45° inclined trinocular head, 360° rotatable, interpupillary distance: 54-76mm, visual adjustment: ±5 diopter. Zoom objective 0.7X-4.5X, working distance: 100mm.
High eyepoint wide field eyepiece WF10X/20mm

Introduction

The AUC-STE-326 series of Stereozoom Microscopes offers sharp 3D images that remain clear throughout the zoom range. This microscope is highly popular and cost-effective. Optional eyepieces and auxiliary objectives can expand the magnification range and working distances. Additional illumination options are available.

Features

1.Larger magnification

7×-45× zoom magnification power with sharp images, the zoom range can be extended from 3.5×-180× with optional eyepieces and auxiliary objectives.

2.Eyepieces

High eyepoint WF10×/20mm eyepieces.

3.Effective working distance

Long working distance to create enough space for the users.

4.Structure design of ergonomics

Ergonomic design, sharp image, wide viewing field, high depth of field and easy to operate, less fatigue when used over a long period.

Applications

The AUC-STE-326 series of microscopes are widely used in education, lab research, biology, metallurgy, engineering, chemistry, manufacturing, and in the medical, forensic science and veterinary industries. The microscope can be used for circuit board repair and inspection, SMT work, electronics inspection, dissection, coin collecting, gemology and gemstone setting, engraving, repair and inspection of small parts.

Optical Parameters

Optional Accessories

High eyepoint wide field eyepiece WF10X/20mm, with micrometer
High eyepoint wide field eyepiece WF10X/20mm, with adjustable diopter
High eyepoint wide field eyepiece WF10X/20mm, with micrometer and adjustable diopter
High eyepoint wide field eyepiece WF15X/15mm
High eyepoint wide field eyepiece WF15X/15mm, with micrometer
High eyepoint wide field eyepiece WF15X/15mm, with adjustable diopter
High eyepoint wide field eyepiece WF15X/15mm, with micrometer and adjustable diopter
High eyepoint wide field eyepiece WF20X/10mm
High eyepoint wide field eyepiece WF20X/10mm, with micrometer
High eyepoint wide field eyepiece WF20X/10mm, with adjustable diopter
High eyepoint wide field eyepiece WF20X/10mm, with micrometer and adjustable diopter
